- General Information
- Manufacturer
- StarTech.com
- Manufacturer Website Address
- http://www.startech.com/au
- Brand Name
- StarTech.com
- Packaged Quantity
- 1
- Product Type
- Gigabit Ethernet Card
Add a 10/100/1000Mbps Ethernet port to any PC through a PCI Express slot. The ST1000SPEX2L Low-Profile PCIe Gigabit Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.
Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter offers effective network performance.
The card comes pre-configured with a low-profile/half-height installation bracket and includes a standard profile bracket for installation in a wide range of computer/server chassis, regardless of form factor.
Backed by a 2-year StarTech.com warranty and free lifetime technical support.
- Warranty
- Limited Warranty
- 2 Year
- Interfaces/Ports
- Host Interface
- PCI Express
- Total Number of Ports
- 1
- Network (RJ-45)
- Yes
- USB
- No
- Serial Port
- No
- Ethernet AUI
- No
- XJACK
- No
- PoE (RJ-45) Port
- No
- Number of Network (RJ-45) Ports
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Data Transfer Rate
- 1024 MB/s
- Network & Communication
- Network Technology
- 10/100/1000Base-T
- Physical Characteristics
- Card Length
- Half-length
- Card Height
- Low-profile
- Form Factor
- Plug-in Card
- Height
- 48.3 mm
- Width
- 17.8 mm
- Length
- 71.1 mm
- Thickness
- 17.8 mm
- Weight (Approximate)
- 31.2 g
- Miscellaneous
- Device Supported
- PC
- Platform Supported
- PC
- Mac
- System Requirements
- OS Compatibility:
- Windows 8 / 8.1 (32/64bit)
- Windows 7 (32/64)
- Windows Vista(32/64)
- Windows XP(32/64)
- Windows 2000
- Windows Server 2012
- Windows 2008 R2
- Windows 2003(32/64)
- Mac OS 10.x (Intel based tested up to 10.9)
- Linux 2.4.x and later (Tested up to 3.5)
