The NH-D15 chromax.black is an all-black version of Noctua’s award-winning flagship model NH-D15 premium-quality quiet CPU cooler. Thanks to the same proven dual-tower heatsink design and NF-A15 PWM fans, it stays true to the NH-D15’s successful formula of rivalling the performance of all-in-one water coolers while maintaining superb quietness of operation. At the same time, the chromax.black version with its black fans and black coated heatsink combines these assets with a sleek stealth look. Topped off with the renowned SecuFirm2™ multi-socket mounting system, Noctua’s enthusiast-grade NT-H1 thermal compound and a full 6-year manufacturer’s warranty, the NH-D15 chromax.black is a deluxe choice for both overclockers and silent enthusiasts who seek an elite-class heatsink that looks just as great as it cools.
| Cooler Specification | |
| Model Number | NH-D15-CH-BK |
| Socket compatibility | Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), Intel LGA1700 (included since Q4 2021, older coolers require NM-i17xx-MP83), LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4, AM5 |
| Height (without fan) | 160 mm |
| Width (without fan) | 150 mm |
| Depth (without fan) | 135 mm |
| Weight (without fan) | 980 g |
| Height (with fan) | 165 mm |
| Width (with fan) | 150 mm |
| Depth (with fan) | 161 mm |
| Weight (with fan) | 1320 g |
| Material | Copper (Base and Heat-Pipes), Aluminium (Cooling Fins), Soldered Joints & Nickel Plating |
| NSPR | 183 |
| Fan Compatibility | 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 |
| Scope of Delivery | Black NH-D15 heatsink 2x NF-A15 HS-PWM chromax.black premium fan 2x Low-Noise Adaptor (L.N.A.) 4-pin PWM Y-cable NT-H1 high-grade thermal compound Black SecuFirm2™ Mounting Kit Noctua Metal Case-Badge |
| Warranty | 6 Years |
| Fan Specification | |
| Model | 2x Noctua NF-P14 PWM & Noctua NF-P12 PWM |
| Bearing | SSO2 |
| Max Rotational speed (+/- 10%) | 1500 RPM |
| Max Rotational speed with L.N.A. (+/- 10%) | 1200 RPM |
| Min. rotational speed (PWM, +/-20%) | 300 RPM |
| Max. Airflow | 140,2 m³/h |
| Max. Airflow with L.N.A. | 115,5 m³/h |
| Max. Acoustical Noise | 24,6 dB(A) |
| Max. acoustical noise with L.N.A. | 19,2 dB(A) |
| Voltage Range | 12 V |
| MTTF | > 150.000 h |
