The D-Link DWC-1000 Wireless Controller is a centralized wireless LAN manager developed specifically for campuses, branch offices, and smallto- medium enterprises (SMBs). With the ability to manage up to six wireless access points (upgradable to 24) and a maximum of 96 wireless access points in a Controller Cluster, the DWC-1000 is a costeffective mobility solution for small to medium-scale environments. Its auto-managed AP discovery and single point management allow customers to acquire an enterprise class system without the burden of executing massive and complex configurations. With a robust and comprehensive security detection system, the DWC-1000 also enables managed APs to block potential attacks from unauthorized users and devices, especially for wireless environments.
- General Information
 - Manufacturer
 - D-Link Systems, Inc

- Manufacturer Website Address
 - http://www.dlink.com.au

- Brand Name
 - D-Link

- Product Type
 - Wireless LAN Controller

- Warranty
 - Limited Warranty
 - Lifetime

- Technical Information
 - ISM Band
 - No

- UNII Band
 - No

- Wireless Security
 - IPSec
 - PPTP
 - L2TP
 - SSL
 - VPN
 - Web Content Filtering
 - Rogue AP Detection
 - Wireless Instruction Detection System
 - NAT
 - PAT
 - DES
 - 3DES
 - AES
 - MD5
 - SHA1
 - Twofish
 - Blowfish
 - CAST-128
 - Dead Peer Detection
 - IP Encapsulating Security Payload (ESP)
 - IP Authentication Header (AH)

- Interfaces/Ports
 - Ethernet Technology
 - Fast Ethernet

- Gigabit Ethernet

- Number of Network (RJ-45) Ports
 - 6

- Network (RJ-11)
 - No

- PoE (RJ-45) Port
 - No

- VGA
 - No

- HDMI
 - No

- Audio Line Out
 - No

- Serial Port
 - No

- USB
 - Yes

- Powerline
 - No

- Management Port
 - Yes

- Management & Protocols
 - Management
 - Web Based Management
 - Command Line Interface
 - SNMP v1/v2c/v3
 - VLAN

- Power Description
 - Input Voltage
 - 110 V AC

- 220 V AC

- Physical Characteristics
 - Form Factor
 - Desktop

- Height
 - 44 mm

- Width
 - 280 mm

- Depth
 - 180 mm

- Miscellaneous
 - Certifications & Standards
 IEEE Standards:
- IEEE 802.3
 - IEEE 802.3u
 - IEEE 802.3ab
 - IEEE 802.1x
 - IEEE 802.1Q

EMI:
- FCC Class B
 - CE Class B
 - VCCI
 - C-tick
 - IC

Safety:
- cUL
 - LVD (EN60950-1)
