Details:
The VE812R HDMI Over Single Cat 5 Receiver supports HDBaseT technology that uses a single Cat 5e cable to extend signals up to 100 m.The VE812R not only supports HDMI (3D, Deep Color) but also Ultra HD (4k) and is HDCP compatible. Furthermore remote EDID pass-through ensures optimum video quality for your HDMI display.
The VE812 is perfect for the meeting room, home theater or any installation that needs long distance transmission and superior video quality.
ATEN VE-812R is designed to work with VS-1814T, VS-1818T or VM-8514 only.
Specifications:
- Video Output: Interface 1 x HDMI Type A Female (Black)
- Impedance: 100 ?
- Video: Max. Data Rate 10.2 Gbps (3.4 Gbps Per Lane)
- Max. Pixel Clock: Up to 340 MHz
- Compliance: HDMI (3D, Deep Color, 4K) HDCP Compatible Consumer Electronics Control (CEC)
- Max Resolutions / Distance: Up to 4K@70m (Cat 5e/6); 1080p@100m
- Audio Output: 1 x HDMI Type A Female (Black)
- Power: Connector:1 x DC Jack Consumption:5.3 VDC, 4.5W
- Environment: Operating Temp. 0-50°C
- Storage Temp.: -20 - 60°C
- Humidity: 0-80% RH, Non-Condensing
- Physical Properties: Housing Metal
- Weight: 0.43 kg
- Dimensions (L x W x H): 14.17 x 10.30 x 3.00 cm
